New Dark series with Ionizer, innovative design, Α+++ energy class, 4 Way Air Flow & Wi-Fi!

  • Maximum protection against germs, bacteria and viruses thanks to the built-in Ionizer
  • Impressive design that upgrades every place
  • Energy saving and excellent performance with Energy Class A +++
  • Uniform air distribution and balanced temperature thanks to 4-way Air Flow
  • Absolute comfort in setting the air-conditioner from wherever you are thanks to the smart remote management via Wi-Fi

The Ionizer ensures in a natural and effective way, the removal of malicious floating particles, such as germs, bacteria, viruses, smoke, dust, odors etc., and offers supreme cleanliness air that inspires a sense of freshness and reliefs you of the disturbing consequences of a poor quality atmosphere, indoors.

Upgrade the aesthetics of your place with the innovative design of the black mirror that adapts to the requirements of each decoration you wish to give to your home.

The innovative technology of Inventor air conditioners, ensures excellent performance at the lowest cost. Take advantage of the highest energy class A+++ and achieve great energy and money savings! Create and enjoy the most ideal atmosphere in your place.

The renewed design creates uniform air distribution in all dimensions. The vent swings not only move horizontally but vertically as well dispersing the air smoothly even in the most difficult spots.

Control your climate easily from wherever you are, with your Smartphone or Tablet. Free download the Invmate II or the Ewpe or the Smart Clima application via Google Play & App Store, depending on the series you have and achieve optimal temperature conditions with great energy savings.

ASK US FOR A QUOTE
  • DRVI32-09WF/ DRVO32-09
  • Cooling Capacity 9.000 (2.730-12.620) Btu / h
  • Cooling Capacity 2.6 (0.8-3.2) kWatt
  • Heating Capacity 11.000 (2.730-14.330) Btu / h
  • Heating Capacity 3.2 (0.8-4.2) kWatt
  • Seasonal Efficiency
    (In accordance to EN14825)
  • Cooling
  • Pdesign 2.6 kW
  • Energy Class A+++
  • SEER 8.5
  • Annual Power Consumption 107 kWh / year
  • Heating Middle Zone
  • Pdesign 2.4 kW
  • Energy Class A++
  • SCOP 4.6
  • Annual Power Consumption 731 kWh / year
  • Heating Warm Zone
  • Pdesign 2.6 kW
  • Energy Class A+++
  • SCOP 5.5
  • Annual Power Consumption 662 kWh / year
  • Voltage / Frequency / Phase 230 / 50 / 1 V / Hz / Ph
  • Current Input - Cooling 2.9 (0.9-6.7) Α
  • Current Input - Heating 3.6 (1.3-7.2) Α
  • Power Input - Cooling 650 (200-1.500) W
  • Power Input - Heating 800 (300-1.600) W
  • Air Flow Volume (Turbo/High/Medium/Low) 650/600/500/450 m³ / h
  • Noise Level - Indoor unit
    (Silent/Low/Medium/High)     20/25/30/35 db(A)
  • Noise Level - Outdoor unit 47 db(A)
  • Sound Power Level - Indoor unit 54 db(A)
  • Sound Power Level - Outdoor unit 59 db(A)
  • Compressor Type ROTARY
  • Liquid line | Gas line 1 / 4” - 3 / 8”
  • Power Supply Wire Outdoor  / Fuses (Noxmm²)/(A) 3 × 1.5 / 10 No x mm² / Α
  • Signal Wires 4 × 1.5 No x mm²
  • Dimensions - Indoor unit
    (WxDxH)     887x211x281 mm
  • Dimensions - Outdoor unit
    (WxDxH)     800x280x550 mm
  • Net Weight -
    Indoor/Outdoor     10.0/29.0 kg
  • Refrigerant/Charge R32/650 g
  • Outdoor Operation
    Temperature Range - Cooling     -10~43 °C
  • Outdoor Operation
    Temperature Range - Heating     -15~24 °C
  • DRVI32-12WF/ DRVO32-12
  • Cooling Capacity 12.000 (3.410-13.650) Btu / h
  • Cooling Capacity 3.5 (1.0-4.0) kWatt
  • Heating Capacity 14.500 (3.410-17.740) Btu / h
  • Heating Capacity 4.2 (1.0-5.6) kWatt
  • Seasonal Efficiency
    (In accordance to EN14825)
  • Cooling
  • Pdesign 3.5 kW
  • Energy Class A+++
  • SEER 8.5
  • Annual Power Consumption 144 kWh / year
  • Heating Middle Zone
  • Pdesign 2.8 kW
  • Energy Class A++
  • SCOP 4.6
  • Annual Power Consumption 854 kWh / year
  • Heating Warm Zone
  • Pdesign 3.0 kW
  • Energy Class A+++
  • SCOP 5.5
  • Annual Power Consumption 756 kWh / year
  • Voltage / Frequency / Phase 230 / 50 / 1 V / Hz / Ph
  • Current Input - Cooling 3.9 (1.4-6.7) Α
  • Current Input - Heating 5.0 (1.3-7.2) Α
  • Power Input - Cooling 875 (300-1.500) W
  • Power Input - Heating 1.100 (500-1.600) W
  • Air Flow Volume (Turbo/High/Medium/Low) 700/650/550/500 m³ / h
  • Noise Level - Indoor unit
    (Silent/Low/Medium/High)     22/29/33/38 db(A)
  • Noise Level - Outdoor unit 48 db(A)
  • Sound Power Level - Indoor unit 58 db(A)
  • Sound Power Level - Outdoor unit 61 db(A)
  • Compressor Type ROTARY
  • Liquid line | Gas line 1 / 4” - 3 / 8”
  • Power Supply Wire Outdoor  / Fuses (Noxmm²)/(A) 3 × 1.5 / 10 No x mm² / Α
  • Signal Wires 4 × 1.5 No x mm²
  • Dimensions - Indoor unit
    (WxDxH)     887x211x281 mm
  • Dimensions - Outdoor unit
    (WxDxH)     800x280x550 mm
  • Net Weight -
    Indoor/Outdoor     10.0/31.5 kg
  • Refrigerant/Charge R32/940 g
  • Outdoor Operation
    Temperature Range - Cooling     -10~43 °C
  • Outdoor Operation
    Temperature Range - Heating     -15~24 °C
  • DRVI32-18WF/ DRVO32-18
  • Cooling Capacity 18.000 (4.430-19.790) Btu / h
  • Cooling Capacity 5.0 (1.30-5.80) kWatt
  • Heating Capacity 18.150 (4.770-20.470) Btu / h
  • Heating Capacity 5.2 (1.4-6.0) kWatt
  • Seasonal Efficiency
    (In accordance to EN14825)
  • Cooling
  • Pdesign 5.0 kW
  • Energy Class A++
  • SEER 6.1
  • Annual Power Consumption 287 kWh / year
  • Heating Middle Zone
  • Pdesign 4.6 kW
  • Energy Class A+
  • SCOP 4.0
  • Annual Power Consumption 1.610 kWh / year
  • Heating Warm Zone
  • Pdesign 4.6 kW
  • Energy Class A+++
  • SCOP 5.1
  • Annual Power Consumption 1.263 kWh / year
  • Voltage / Frequency / Phase 230 / 50 / 1 V / Hz / Ph
  • Current Input - Cooling 6.5 (1.8-8.9) Α
  • Current Input - Heating 6.3 (2.3-11.3) Α
  • Power Input - Cooling 1.460 (400-2.000) W
  • Power Input - Heating 1.400 (520-2.500) W
  • Air Flow Volume (Turbo/High/Medium/Low) 1.000/900/800/600 m³ / h
  • Noise Level - Indoor unit
    (Silent/Low/Medium/High)     30/35/40/44 db(A)
  • Noise Level - Outdoor unit 53 db(A)
  • Sound Power Level - Indoor unit 59 db(A)
  • Sound Power Level - Outdoor unit 65 db(A)
  • Compressor Type ROTARY
  • Liquid line | Gas line 1 / 4” - 1 / 2”
  • Power Supply Wire Outdoor  / Fuses (Noxmm²)/(A) 3 × 2.5 / 16 No x mm² / Α
  • Signal Wires 4 × 1.5 No x mm²
  • Dimensions - Indoor unit
    (WxDxH)     1.030x233x322 mm
  • Dimensions - Outdoor unit
    (WxDxH)     800x280x550 mm
  • Net Weight -
    Indoor/Outdoor     13.0/32.7 kg
  • Refrigerant/Charge R32/900 g
  • Outdoor Operation
    Temperature Range - Cooling     -10~43 °C
  • Outdoor Operation
    Temperature Range - Heating     -15~24 °C
  • DRVI32-24WF/ DRVO32-24
  • Cooling Capacity 24.000 (7.500-29.000) Btu / h
  • Cooling Capacity 7.0 (2.2-8.5) kWatt
  • Heating Capacity 28.000 (8.190-34.120) Btu / h
  • Heating Capacity 8.1 (2.40-10.0) kWatt
  • Seasonal Efficiency
    (In accordance to EN14825)
  • Cooling
  • Pdesign 7.0 kW
  • Energy Class A++
  • SEER 7.1
  • Annual Power Consumption 350 kWh / year
  • Heating Middle Zone
  • Pdesign 5.6 kW
  • Energy Class A+
  • SCOP 4.0
  • Annual Power Consumption 1.963 kWh / year
  • Heating Warm Zone
  • Pdesign 5.6 kW
  • Energy Class A+++
  • SCOP 5.1
  • Annual Power Consumption 1.537 kWh / year
  • Voltage / Frequency / Phase 230 / 50 / 1 V / Hz / Ph
  • Current Input - Cooling 9.6 (3.2-13) Α
  • Current Input - Heating 9.7 (3.2-13) Α
  • Power Input - Cooling 2.160 (700-2.900) W
  • Power Input - Heating 2.180 (700-2.900) W
  • Air Flow Volume (Turbo/High/Medium/Low) 1.300/1.200/1.000/850 m³ / h
  • Noise Level - Indoor unit
    (Silent/Low/Medium/High)     30/37/43/47 db(A)
  • Noise Level - Outdoor unit 52 db(A)
  • Sound Power Level - Indoor unit 60 db(A)
  • Sound Power Level - Outdoor unit 65 db(A)
  • Compressor Type ROTARY
  • Liquid line | Gas line 1 / 4” - 1 / 2”
  • Power Supply Wire Outdoor  / Fuses (Noxmm²)/(A) 3 × 2.5 / 16 No x mm² / Α
  • Signal Wires 4 × 1.5 No x mm²
  • Dimensions - Indoor unit
    (WxDxH)     1.115x248x336 mm
  • Dimensions - Outdoor unit
    (WxDxH)     890x353x697 mm
  • Net Weight -
    Indoor/Outdoor     16.0/51.0 kg
  • Refrigerant/Charge R32/1.200 g
  • Outdoor Operation
    Temperature Range - Cooling     -10~43 °C
  • Outdoor Operation
    Temperature Range - Heating     -15~24 °C

Activate the Ultra Silence Mode and enjoy an absolute feeling of pure silence in your room.

Ultra Silence Mode

The outdoor unit’s special design produces an efficient and effective cooling operation even at -10°C.

The exquisite filter optimizes the filtering effect by 40%.

High Density Air Dust Filter

Set the unit to start and stop automatically in a 24h period.

24-hour Timer

With the Sleep Mode, the air conditioner adjusts the room temperature for perfect sleeping conditions and great energy savings.

Sleep Mode

Distributes cool/warm air to maximum area by moving horizontal flaps automatically.

Horizontal louver will automatically move to the same position as you set last time when the unit turned on

Indoor fan speed is regulated automatically from the lowest grade to the setting grade according to the evaporator temperature when the unit starts heating operation

This function gives you a boost in cooling and heating power for a period and makes the room cool down or heat up rapidly.

Turbo Mode

If the air conditioner breaks off unexpectedly due to the power cut, it will restart with the previous setting mode automatically when the power resume.

Auto Restart

Once abnormal operation or parts failure happens, the unit will shut off automatically to protect the system. Meanwhile it will indicate protection or error code for fast service.

Auto Error Diagnosis

The R32 ECO Refrigerant with 68% lower global warming potential, is here to significantly enhance your air conditioner performance and to drastically contribute to global warming protection. It does not adversely affect the ozone layer, contributes in reducing global warming effect by entrapping smaller amounts of heat (GWP = 675) and can be easily reused and recycled.

R32 ECO Refrigerant

Indoor unit will show error code “EC” and will stop automatically when refrigerant leakage is detected

Both left and right sides of the indoor unit are possible for drainage hose connection, easy for installation.

The fan motors of the indoor and outdoor units as well as the compressor have been upgraded to All DC Inverter technology. In this way, the compressor can change the capacity depending on the needs of the indoor atmosphere and create perfect conditions in your space.

Engage the lock function to prevent anyone from changing the settings or children playing with the unit.
