High levels of comfort and efficiency for your business

  • Super slim design for easy installation
  • Capability of a vent connection
  • Built-in drain pump

The innovative technology of Inventor air conditioners, ensures excellent performance at the lowest cost. Take advantage of the highest energy class A+++ and achieve great energy and money savings! Create and enjoy the most ideal atmosphere in your place.

The ultimate protection of the air conditioner, especially at areas with high humidity levels and increased corrosive possibility, such as islands and coastal areas, can now be achieved. The golden, anticorrosive coating of the outdoor unit’s refrigerant, protects against salty air, rain and other corrosive elements, ensuring the effective performance of the air conditioner and the extension of its lifeline. The golden coating of the indoor unit refrigerant, thanks to its antibacterial action, allows you to enjoy a perfectly clean and healthy atmosphere!

The R32 ECO Refrigerant with 68% lower global warming potential, is here to significantly enhance your air conditioner performance and to drastically contribute to global warming protection. It does not adversely affect the ozone layer, contributes in reducing global warming effect by entrapping smaller amounts of heat (GWP = 675) and can be easily reused and recycled.

Control your climate easily from wherever, with your Smartphone or Tablet. Download the app, Invmate II, for free via Google Play & App Store and set your temperature conditions.

Take advantage of the Weekly Planner and adjust according to your needs, the air conditioner’s operating period, ensuring maximum energy and money savings. The new advanced wired controller, shows up the error codes and additionally enables you to activate the room temperature sensor via the wired controller instead of the air conditioner.

With the advanced technology of the new air Duct units, you can set the available static pressure depending on your plant’s duct network, from 0Pa to 160Pa.

The drain pump can lift the condensing water up to 750mm, serving every kind of installation. Refers to chest installations.

With a smart control board, air conditioners can be turned on/off via long distance control signals.

Provided to handle the fresh air load for a clean and healthy environment.

The innovative design of the new Duct series, enable you to install your air conditioner whenever you want, always based on your place's requirements. Select between the chest and the upright placement and enjoy the ideal situation easily and fast. *Refers to V5MDI32-36WiFiRB/ V5MDI32-50WiFiRB/ V5MDI32-60WiFiRB series

Inventor air conditioners present the innovative air-conditioning unit management "HOTEL MENU". The HOTEL MENU is a set of features specifically designed to help better and more economical operation of air conditioners installed in hotel units.

ASK US FOR A QUOTE
  • MODEL V5MDI32-12WiFiRΒ
    U5MRS32-12
  • Cooling Capacity 12.000 Btu / h
  • Heating Capacity 14.000 Btu / h
  • Cooling Capacity Range (5.100-16.200) Btu / h
  • Cooling Capacity Range 3.51 (1.49-4.75) kWatt
  • Heating Capacity (3.300-19.200) Btu / h
  • Heating Capacity 4.10 (0.97-5.63) kWatt
  • Seasonal Efficiency Cooling In accordanceto EN14825
  • Pdesign 3.5 kW
  • Energy Class Α++
  • SEER 6.5
  • Seasonal Efficiency Heating (Middle Zone) In accordanceto EN14825
  • Pdesign 3.2 kW
  • Energy Class A+
  • SCOP 4.0
  • Seasonal Efficiency Heating (Warm Zone) In accordanceto EN14825
  • Pdesign 3.7 kW
  • Energy Class Α++
  • SCOP 4.8
  • Voltage / Frequency / Phase 220-240 / 50 / 1 V / Hz / Ph
  • Current Input Cooling / Heating 1.7-7.2/1.7-9.0 A
  • Power Input Cooling / Heating 350-1.620/350~2.050 W
  • Air Flow Volume (High / Medium / Low) 600/480/300 m3 / h
  • Outdoor Static Pressure 0-60 Pa
  • Noise Level Indoor unit (Low / Medium / High) 26/30.5/35 dB(A)
  • Noise Level Outdoor unit 55.5 dB(A)
  • Sound Power Level 56/61 dB(A)
  • Power Supply Wire Outdoor / Fuses ( 3x2.5/1x16 No x mm2 / A
  • Signal Wires 3x1.5 & (2x1.0 Shield) No x mm2
  • Dimensions Indoor unit WxDxH 700x450x200 mm
  • Dimensions Outdoor unit WxDxH 800x333x554 mm
  • Net Weight 18/34.7 kg
  • Liquid line - Gas line 1/4"/3/8"
  • Refrigerant / Charge R32/870 g
  • Outdoor Operation Temperature Range Cooling / Heating -15~50/-15~24 oC
  • MODEL V5MDI32-24WiFiR
    U5MRS32-24
  • Cooling Capacity 24.000 Btu / h
  • Heating Capacity 26.000 Btu / h
  • Cooling Capacity Range (11.180-27.830) Btu / h
  • Cooling Capacity Range 7.03 (3.27-8.15) kWatt
  • Heating Capacity (9.280-29.750) Btu / h
  • Heating Capacity 7.62 (2.71-8.72) kWatt
  • Seasonal Efficiency Cooling In accordanceto EN14825
  • Pdesign 7.0 kW
  • Energy Class Α++
  • SEER 6.1
  • Seasonal Efficiency Heating (Middle Zone) In accordanceto EN14825
  • Pdesign 5.1 kW
  • Energy Class A+
  • SCOP 4.0
  • Seasonal Efficiency Heating (Warm Zone) In accordanceto EN14825
  • Pdesign 6.1 kW
  • Energy Class A+++
  • SCOP 5.1
  • Voltage / Frequency / Phase 220-240/50/1 V / Hz / Ph
  • Current Input Cooling / Heating 2.1-12.4/2.2-12.5 A
  • Power Input Cooling / Heating 480-2.850/500-2.880 W
  • Air Flow Volume (High / Medium / Low) 1.248/1.054/839 m3 / h
  • Outdoor Static Pressure 0-160 Pa
  • Noise Level Indoor unit (Low / Medium / High) 38/40/42 dB(A)
  • Noise Level Outdoor unit 62 dB(A)
  • Sound Power Level 62/66 dB(A)
  • Power Supply Wire Outdoor / Fuses ( 3x2.5/1x16 No x mm2 / A
  • Signal Wires 3x1.5 & (2x1.0 Shield) No x mm2
  • Dimensions Indoor unit WxDxH 1.100x774x249 mm
  • Dimensions Outdoor unit WxDxH 845x363x702 mm
  • Net Weight 31.5/66.8 kg
  • Liquid line - Gas line 3/8"/5/8"
  • Refrigerant / Charge R32/1.500 g
  • Outdoor Operation Temperature Range Cooling / Heating -15~50/-15~24 oC
  • MODEL V5MDI32-36WiFiR
    U5MRS32-36
  • Cooling Capacity 36.000 Btu / h
  • Heating Capacity 38.000 Btu / h
  • Cooling Capacity Range (13.800-41.000) Btu / h
  • Cooling Capacity Range 10.55 (4.04-12.02) kWatt
  • Heating Capacity (9.580-45.000) Btu / h
  • Heating Capacity 11.14 (2.81-13.19) kWatt
  • Seasonal Efficiency Cooling In accordanceto EN14825
  • Pdesign 10.5 kW
  • Energy Class Α++
  • SEER 6.1
  • Seasonal Efficiency Heating (Middle Zone) In accordanceto EN14825
  • Pdesign 8.5 kW
  • Energy Class A+
  • SCOP 4.0
  • Seasonal Efficiency Heating (Warm Zone) In accordanceto EN14825
  • Pdesign 10.5 kW
  • Energy Class A+++
  • SCOP 5.1
  • Voltage / Frequency / Phase 220-240/50/1 V / Hz / Ph
  • Current Input Cooling / Heating 4.2-19.6/3.6-18.4 A
  • Power Input Cooling / Heating 902-4.900/800-4.640 W
  • Air Flow Volume (High / Medium / Low) 1.400/1.150/750 m3 / h
  • Outdoor Static Pressure 0-160 Pa
  • Noise Level Indoor unit (Low / Medium / High) 40/43/47 dB(A)
  • Noise Level Outdoor unit 65 dB(A)
  • Sound Power Level 62/68 dB(A)
  • Power Supply Wire Outdoor / Fuses ( 3x4.0/1x25 No x mm2 / A
  • Signal Wires 3x1.5 & (2x1.0 Shield) No x mm2
  • Dimensions Indoor unit WxDxH 1.360x774x249 mm
  • Dimensions Outdoor unit WxDxH 946x410x810 mm
  • Net Weight 40.5/66.8 kg
  • Liquid line - Gas line 3/8"/5/8"
  • Refrigerant / Charge R32/2.400 g
  • Outdoor Operation Temperature Range Cooling / Heating -15~50 /-15~24 oC
  • MODEL V5MDI32-50WiFiR
    U5MRT32-50
  • Cooling Capacity 48.000 Btu / h
  • Heating Capacity 55.000 Btu / h
  • Cooling Capacity Range (14.545-51.845) Btu / h
  • Cooling Capacity Range 14.07 (4.26-15.19) kWatt
  • Heating Capacity (12.621-61.500) Btu / h
  • Heating Capacity 16.12 (3.7-18.02) kWatt
  • Seasonal Efficiency Cooling In accordanceto EN14825
  • Pdesign 14.0 kW
  • Energy Class Α++
  • SEER 6.1
  • Seasonal Efficiency Heating (Middle Zone) In accordanceto EN14825
  • Pdesign 12.0 kW
  • Energy Class A+
  • SCOP 4.0
  • Seasonal Efficiency Heating (Warm Zone) In accordanceto EN14825
  • Pdesign 12.5 kW
  • Energy Class A+++
  • SCOP 5.1
  • Voltage / Frequency / Phase 380-415/50/3 V / Hz / Ph
  • Current Input Cooling / Heating 1.8-9.4/1.5-9.2 A
  • Power Input Cooling / Heating 1.170-5.699/948-5.824 W
  • Air Flow Volume (High / Medium / Low) 2.400/2.040/1.680 m3 / h
  • Outdoor Static Pressure 0-160 Pa
  • Noise Level Indoor unit (Low / Medium / High) 48/50/51 dB(A)
  • Noise Level Outdoor unit 66 dB(A)
  • Sound Power Level 62/72 dB(A)
  • Power Supply Wire Outdoor / Fuses ( 5x2.5 / 3x20 No x mm2 / A
  • Signal Wires 3x1.5 & (2x1.0 Shield) No x mm2
  • Dimensions Indoor unit WxDxH 1.200x874x300 mm
  • Dimensions Outdoor unit WxDxH 952x415x1.333 mm
  • Net Weight 47.6/106.7 kg
  • Liquid line - Gas line 3/8"/5/8"
  • Refrigerant / Charge R32/2.800 g
  • Outdoor Operation Temperature Range Cooling / Heating -15~50 / -15~24 oC
  • MODEL V5MDI32-60WiFiR
    U5MRT32-60
  • Cooling Capacity 52.000 Btu / h
  • Heating Capacity 62.000 Btu / h
  • Cooling Capacity Range (20.000-59.000) Btu / h
  • Cooling Capacity Range 15.4 (5.86-17.29) kWatt
  • Heating Capacity (16.000-70.000) Btu / h
  • Heating Capacity 18.2 (4.69-20.52) kWatt
  • Seasonal Efficiency Cooling In accordanceto EN14825
  • Pdesign 15.4 kW
  • Energy Class Α++
  • SEER 6.1
  • Seasonal Efficiency Heating (Middle Zone) In accordanceto EN14825
  • Pdesign 12.5 kW
  • Energy Class A+
  • SCOP 4.0
  • Seasonal Efficiency Heating (Warm Zone) In accordanceto EN14825
  • Pdesign 13.1 kW
  • Energy Class A+++
  • SCOP 5.1
  • Voltage / Frequency / Phase 380-415/50/3 V / Hz / Ph
  • Current Input Cooling / Heating 2.0-11.6/1.6-10.5 A
  • Power Input Cooling / Heating 1.274-6.651.1.042-6.034 W
  • Air Flow Volume (High / Medium / Low) 2.600/2.210/1.820 m3 / h
  • Outdoor Static Pressure 0-160 Pa
  • Noise Level Indoor unit (Low / Medium / High) 51/52/54 dB(A)
  • Noise Level Outdoor unit 66 dB(A)
  • Sound Power Level 71/74 dB(A)
  • Power Supply Wire Outdoor / Fuses ( 5x2.5 / 3x20 No x mm2 / A
  • Signal Wires 3x1.5 & (2x1.0 Shield) No x mm2
  • Dimensions Indoor unit WxDxH 1.200x874x300 mm
  • Dimensions Outdoor unit WxDxH 952x415x1.333 mm
  • Net Weight 47.6/111.3 kg
  • Liquid line - Gas line 3/8"/5/8"
  • Refrigerant / Charge R32/2.950 g
  • Outdoor Operation Temperature Range Cooling / Heating -15~50 / -15~24 oC
  • MODEL V6MDI32-18WiFiR
    U6MRS32-18
  • Cooling Capacity 18.000 Btu / h
  • Heating Capacity 2.000 Btu / h
  • Cooling Capacity Range (8.700-19.400) Btu / h
  • Cooling Capacity Range 5.28 (2.55-5.69) kWatt
  • Heating Capacity (7.500-21.000) Btu / h
  • Heating Capacity 5.87 (2.20-6.15) kWatt
  • Seasonal Efficiency Cooling In accordanceto EN14825
  • Pdesign 5.3 kW
  • Energy Class Α++
  • SEER 6.1
  • Seasonal Efficiency Heating (Middle Zone) In accordanceto EN14825
  • Pdesign 4.3 kW
  • Energy Class A+
  • SCOP 4.0
  • Seasonal Efficiency Heating (Warm Zone) In accordanceto EN14825
  • Pdesign 5.2 kW
  • Energy Class Α++
  • SCOP 5.0
  • Voltage / Frequency / Phase 220-240/50/1 V / Hz / Ph
  • Current Input Cooling / Heating 3.2-8.3/3.3-7.7 A
  • Power Input Cooling / Heating 710-1.900/740-1.760 W
  • Air Flow Volume (High / Medium / Low) 880/650/350 m3 / h
  • Outdoor Static Pressure 0-100 Pa
  • Noise Level Indoor unit (Low / Medium / High) 33/38/41.5 dB(A)
  • Noise Level Outdoor unit 55 dB(A)
  • Sound Power Level 59/62 dB(A)
  • Power Supply Wire Outdoor / Fuses ( 3x2.5/1x16 No x mm2 / A
  • Signal Wires 3x1.5 & (2x1.0 Shield) No x mm2
  • Dimensions Indoor unit WxDxH 880x674x210 mm
  • Dimensions Outdoor unit WxDxH 800x333x554 mm
  • Net Weight 24.3/33.7 kg
  • Liquid line - Gas line 1/4"/1/2"
  • Refrigerant / Charge R32/1.15 g
  • Outdoor Operation Temperature Range Cooling / Heating -15-50/-15-24 oC

Excellent heating performance even at the most demaning regions with low temperature levels. Ensure the prefered temperature conditions, even at -15°C and enjoy ideal conditions in your place.

Excellent Heating Performance Under -15°C

The fan motors of the indoor and outdoor units as well as the compressor have been upgraded to All DC Inverter technology. In this way, the compressor can change the capacity depending on the needs of the indoor atmosphere and create perfect conditions in your space.

All DC Inverter

Take the whole control of you unit! Thanks to the error code that will appear if an error occurs, you can always be safe and sure for the appropriate and most efficient operation of your air conditioner.

Error Alarm Port

With a smart control board, air conditioners can be turned on/off via long distance control signals.

Front Desk Control On/Off(Optional)

Once abnormal operation or parts failure happens, the unit will shut off automatically to protect the system. Meanwhile it will indicate protection or error code for fast service.

Auto Error Diagnosis

If the air conditioner breaks off unexpectedly due to the power cut, it will restart with the previous setting mode automatically when the power resume.

Auto Restart

Set the unit to start and stop automatically in a 24h period.

24-hour Timer

The outdoor unit’s special design produces an efficient and effective cooling operation even at -15°C.

Once abnormal operation or parts failure happens, the unit will shut off automatically to protect the system. Meanwhile it will indicate protection or error code for fast service.

Take advantage of the 4 choices to adjust the indoor unit’s fan speed and benefit from the Filter Cleaning Reminder mode, the Louver Position Memory, the Temperature Compensation sensor and the Higher/ Lower Temperature settings to create the ideal conditions in your place.
